DIFF Transformer V2: differential attention for LLMs | Keryc
DIFF Transformer V2 arrives as a more practical and stable version of the differential idea in attention. What changes compared to DIFF V1 and why does it matter if you are training or deploying a large language model? Here I explain it with technical clarity but without losing readability.
Qué es DIFF V2 y por qué lo hicieron
DIFF V2 implements the differential operation directly inside attention: it duplicates the query heads to 2h, keeps the key-value (KV) heads at h_kv, and then subtracts head pairs (head 0 minus head 1, head 2 minus head 3, and so on). The subtraction is scaled by a projected per-token-per-head factor lambda, and then reduced back to the original dimension before W_O, so W_O stays identical to the base Transformer.
Why this design? Because it gives you the expressive power of differential attention without paying the cache cost of duplicated values or needing custom attention kernels. In plain terms: you keep decoding speed comparable to a standard Transformer and make the trick usable in real LLMs.
Diseño técnico y piezas clave
Duplicated query heads: DIFF V2 uses 2h query heads but still uses h_kv heads for key and value. After the differential op the dimension returns to h * d so W_O remains compatible.
Projected lambda per token and head: lambda is produced by projecting X (the token representations) and applied through sigmoid to keep the scale bounded. This gives fine-grained control of the Context RMS per head and per token.
No per-head RMSNorm in the context: unlike DIFF V1, DIFF V2 removes per-head RMS normalization in the context because projecting lambda and resizing dimensions fixes the numerical issues that motivated that normalization.
Compatibility with existing kernels: by aligning head dimensions between Q, K and V, DIFF V2 avoids needing special kernels and benefits from modern FlashAttention on H-series and B-series GPUs.
Código conceptual
A simplified skeleton of the two versions helps you see the difference:
Notice two points: in V2 the head pairs are interleaved (0::2 and 1::2) to share the same KV, and lambda is per token-head with sigmoid.
Context RMS y estabilidad numérica
In standard softmax attention, if v_j are assumed to have RMS 1 and be uncorrelated, the Context RMS ends up in the range [1/sqrt(n), 1). What does that mean for you? If attention flattens toward uniform distributions over long sequences, the magnitude drops to 1/sqrt(n).
In DIFF V1 they tried to fix this with a per-head RMSNorm, but that forces multiplication by huge factors when n is large (for example sqrt(8192) is about 90), which produces huge gradients and numerical explosion.
DIFF V2 fixes it differently: by projecting lambda per token and head and removing per-head RMSNorm, the gradient scale becomes comparable to a standard Transformer. In practice this reduces gradient spikes and activation outliers when you train with large learning rates.
Resultados empíricos y comportamiento en entrenamiento
The authors run production-scale pretraining (trillions of tokens, dense models and 30A3 MoE) with large learning rates (6e-4 to 1e-3). What did they see?
Noticeable reduction in language modeling loss compared to the Transformer: a gap of 0.02 to 0.03.
Fewer gradient spikes and activation outliers, especially with large learning rates where the standard Transformer can become unstable.
Throughput overhead in pretraining is negligible if you use FlashAttention on H-series and B-series GPUs.
They also recommend, for long-sequence prefilling, combining DIFF V2 with techniques like YOCO that reduce prefilling complexity to linear time.
Costos, parámetros y comparación teórica
If you compare DIFF V2 with a Transformer that naively has 2h real heads, both have the same attention kernel cost, but DIFF V2 requires fewer parameters in the output projection W_O. With current GQA (grouped query attention) setups, you can save roughly 25% of the attention module parameters, because W_Q and W_O dominate memory and parameters.
Also, if your goal is not just minimal loss but better training stability or tighter control of outliers, DIFF V2 already makes practical sense. Not everything is about the smallest loss: stability and operational efficiency matter too.
Ablaciones importantes y errores comunes
The authors report several ablation tests that show what not to do:
Head pairing mistake: splitting attention halves as attn[:, :nh//2] and attn[:, nh//2:] is incorrect. Differential heads must be interleaved attn[:, 0::2] and attn[:, 1::2] to share the same KV. The wrong implementation causes instability and higher loss.
Omitting lambda in the subtraction: using attn1 - attn2 without scaling leads to a Context RMS that’s too small initially.
Not applying sigmoid to lambda: using the projected lambda without regularization can leave Context RMS unbounded and cause instability.
These three ablations harm training; the first one is the most damaging for stability.
Compatibilidad con sparse attention y consideraciones prácticas
DIFF V2 is compatible with sparse attention schemes. The practical challenge is choosing KV blocks when the differentiated heads form a large GQA group. Possible strategies:
Select blocks based on the average logits between the differentiated heads, or
handle the two classes of heads separately during selection.
Conceptually there’s no fundamental barrier—only an adjustment in block-selection heuristics to keep acceleration.
Recomendaciones para equipo de ML y ML infra
If you use modern FlashAttention on H-series or B-series GPUs, DIFF V2 has small overhead in pretraining.
At decoding, DIFF V2 avoids duplicating the KV-cache load, so it keeps latency and memory use comparable to the base Transformer.
If you plan to train with high learning rates or at production scale, DIFF V2 can give gains in stability and smaller outlier magnitudes.
Be careful when implementing head indexing and the projection of lambda (use sigmoid).
DIFF V2 is not just a theoretical curiosity: it’s a practical reformulation of differential attention that prioritizes stability, compatibility with existing kernels, and decoding efficiency.
